About Trinocular Coaxial Microscope
Trinocular Coaxial Microscope
Trinocular Coaxial Microscope availed by us is especially designed for the study microorganism and microstructures in forensic labs, medical applications, school and university laboratories. The frame is fabricated by using best grade aluminium with the help of pressurized die casting process and is also provided with a Polyurethane coating to prevent surface damage. Trinocular Coaxial Microscope offered by us has a quadruple nose with a binocular head which is capable to rotate around 360 degrees and can be inclined up to about 45 degrees. The prism and the lenses fixed in the device is coated with anti-fungus coating
Specifications :
- Frame- All aluminum pressure diecasted body.
- Paint- P.U. coating in light cream shade.
- Nose piece- Ultra Quadruple ball bearing nosepiece.
- Binocular head-360* rotate able and 45* inclined head with all anti-fungus coated prisms.
- Focusing system fine Co- axial focusing system with three planetary gears assb. With slide protection lock.
- Mechanical stage- Cxl Ball bearing double layer mechanical stage for smooth functioning.
- Condenser- Condenser Bright field sub stage condenser having 1.2 N.A.
- Objectives- ACHROMATIC 4x, 10x, 40x, and 100x
- Eye piece- WF-10 X (18mm)
- Illumination- LED LIGHT 3.5W , 3V needs 220v (50Hz), 110V(60Hz) optional supply.
Optional accessories :
- 2/3 Mega pixel Digital Camera for Microscope
- Phase contrast kit.
- Dark filled condensor
- Digital Camera(10/12/15 Mega Pixel)
- Image Analysis Software
Versatile Application and Precision OpticsThis microscope is engineered with achromatic objectives that deliver sharp, color-corrected images at all magnifications, from general observation at 5x to extreme detail using 100x oil immersion. Its trinocular head provides the flexibility for both eyepiece observation and digital imaging, supporting various work settings from classrooms to advanced labs.
Reliable Distribution Across IndiaAs a leading product among dealers, distributors, exporters, fabricators, manufacturers, suppliers, traders, and wholesalers, this microscope is readily available throughout India. Backed by robust after-sales support, it meets the standards needed for scientific and industrial institutions nationwide.
FAQ's of Trinocular Coaxial Microscope:
Q: How do I use the oil immersion objective for optimal clarity?
A: To use the 100x oil immersion objective, place a small drop of immersion oil on the slide, gently lower the objective into the oil, and adjust focus slowly. This reduces light refraction, resulting in superior image resolution.
Q: What is the benefit of the trinocular drawtube?
A: The trinocular drawtube enables simultaneous viewing through eyepieces and a camera or imaging system, making it suitable for demonstrations, documentation, and collaborative work.
Q: When should I use each magnification level (5x, 10x, 40x, 100x)?
A: Start with 5x or 10x for scanning and locating areas of interest. Use 40x for moderate detail observations. Reserve the 100x oil immersion lens for studying fine cellular details or microorganisms.
Q: Where can I purchase the Trinocular Coaxial Microscope in India?
A: This microscope is available across India through authorized dealers, distributors, fabricators, manufacturers, suppliers, traders, and wholesalers. Contact your preferred supplier for purchase and delivery details.
Q: What is the typical process for setting up the microscope after delivery?
A: Unpack the microscope and assemble according to the user manual. Connect to a 110V power source, attach objectives and eyepieces, and calibrate the focus before use.
Q: How does achromatic objective design enhance usage?
A: Achromatic objectives minimize color distortion and deliver sharper, true-to-life images, greatly benefiting detailed microscopy work in research, clinical, and educational settings.
